Signal Fire AI-6A Fiber Fusion Splicer Machine

The Signal Fire AI-6A Fiber Fusion Splicer is a professional-grade fiber optic splicing machine designed for FTTH, ISP, and telecom installations. Featuring advanced 6-motor core alignment technology, the AI-6A delivers fast, accurate, and low-loss fiber splicing performance for both single-mode and multimode fibers. [3]Equipped with a high-definition touchscreen display and intelligent calibration system, the splicer ensures easy operation and stable performance even in demanding field environments. Its compact and portable design makes it ideal for technicians working on FTTH deployments, backbone fiber networks, and maintenance projects. [1]The AI-6A supports rapid heating and splicing, reducing installation time while improving productivity. It also includes long battery life, USB support, automatic fiber identification, and durable construction for outdoor use.Basic Parameter of Signal Fire AI-6A   Fiber alignment  Core/cladding  Motor number  6 motors  Splicing time  8s  Heating mode  18s， can be customized according to the external environment  Fiber type  Single-mode fiber (SMF/G.652), multimode fiber (MMF/G.651), dispersion-shifted fiber (DSF/G.653), G.654 fiber, non-zero dispersion-shifted fiber (NZ-DSF/G.655), and bend-insensitive fiber (BIF/G.657); suitable for splicing bare fiber, pigtail, drop fiber, patch cord, and invisible fiber.  The cladding diameter  80-150μm  Splicing loss  0.02dB（SM）、0.01dB（MM）0.04dB（DS/NZDS）  Splicing mode  Automatic focusing core alignment, conventional/high precision welding  Splicing way  Automatic, semi-automatic  Fiber holder  Three in one fixture, no need to change, suitable for single/multi-mode, multi-core cable/bare fiber, tail fiber, jumper fiber,drop cable  Battery capacity  5200mAh large capacity lithium battery charging time ≤3.0; It can continuously weld and heat about 160 cores  Magnification  300x (X or Y axis single display) 150x (x and Y axis dual display)  Fiber diameter  Coating diameter: 80-150μm/Coating diameter: 100-1000μm  Cutting length  Coating layer 250μm below: 8-16mm/coating layer 250-1000μm: 16mm  Heat shrink tube  60mm、50mm、40mm、25mm  Tensile testing  standard 2N  Display  5-inch color touchscreen  Boot time  1s, boot can enter the working mode Signal Fire AI-6A   Data is stored  Unlimited, machine storage 1000 groups, the excess part can be stored in the server, can export data.  Wireless communication  Based on bluetooth 4.2 protocol standard, the working band is 2.4GHz, the maximum transmission range is 60m  Software upgrade  Mobile phone APP Internet update, enable Bluetooth synchronization upgrade machine software  Management function  The equipment owner can be bound as the highest authority, and can remotely view the welding records,welding time, loss, etc. through the mobile phone APP. The number of welding times or working time of the equipment can be set. The manager can effectively manage a single or multiple equipment.  Return loss  Better than 60 db  Product protection  Waterproof, dustproof and fall proof  Power supply  Input AC100-240V 50/60Hz, output DC13.5V/4.8A, the current power mode can be identified, real-time monitoring of the current battery level  The work environment  Temperature: -15 ~ 50℃, humidity: < 95%RH (no condensation), working altitude: 0 ~ 5000m, maximum wind speed: ≤15m/sSize and wight of Signal Fire AI-6A Machine weight：1.99kg（including batteries）   1.63kg（excluding batteries）Tool box weight：4.70kg(including machine and accessories)Carton weight：5.9kgThree years warranty, but these circumstances are not within the scope of this provision.01.Except for the cleaver, miller clamp, stripping pliers, fiber holders and other tools whose life depends on the frequency of use and the use of the environment. Also electrodes are consumption material which are not in the warranty. 02.Battery and power adapter are warranty for one year, it is in free warranty where it is damaged or can not be charged in one year.
